Specs
Dimensions (HWD)
270 x 390 x 135 mm (10.6 x 15.3 x 5.3 in)
Weight
4kg (8.8 lb)
Operating temperature
-25°C to 45°C (-13°F to 113°F)
Storage Temperature
-25°C to 70°C (-13°F to 158°F)
Feed-in type(AC Distribution Board)
Split phase (L1, L2, N)
Input(AC Distribution Board)
Max 50A, 120/240V, 60Hz
Maximum Input Short-circuit Current(AC Distribution Board)
10kA
Output(AC Distribution Board)
Max 30A for each branch circuit
AC Circuit(AC Distribution Board)
12 branch circuits breaker stabs
Strain Relief knockout(AC Distribution Board)
2x3/4 inch, 1x1 inch
Input(AC Distribution Board)
Max 100A, 13/26V⎓
Output(AC Distribution Board)
F1-F13: rated up to 30A, continuous operating current <20A
F14F16: rated up to 50A, continuous operating current <33A
Number of Circuits(AC Distribution Board)
16 controllable circuits (F1-F16)
Encolsure Type
NEMA Type 1
Compliance
UL67, FCC Class A compliant
Warranty
5 Years
