Quiet Comfort for Your Home and Neighbors, Too!
It's whisper-quiet with X-Quiet technology, ensuring a peaceful hum*, promising you a night of peaceful sleep even if you keep it beside your bed. It's so silent that you'll hardly notice it's there.
*as low as 30 dB, thanks to our X-Quiet tech
Charge up, fast, and everywhere
Introducing EcoFlow's groundbreaking X-Stream fast charging technology, setting a new industry standard. Charge from 0 to 80% in just 50 minutes. With multi-charge combinations, enjoy up to 7000W of super-fast charging.
7 unique and 18 combo charging methods to meet your charging needs anywhere, anytime
Indoor: Dual-PV Charging
Indoor: AC Wall Charging
Garage: EcoFlow Smart
Home Panel 2
Backyard: With Gas
Generator
Outdoor: EV Charging
Piles
RV/Van: EcoFlow
Alternator Charger
Car: Cigarette Lighter
Charging
Fast Multi-Charging
Solutions
Effortless All-in-One Command with the EcoFlow App
Installation Consulting Service For EcoFlow Smart Home Panel 2
With our service, you'll experience a seamless EcoFlow Smart Home Panel 2 installation. We connect you with a fully-trained local electrician and provide tracking from order to fitting. Our team is on hand to answer any technical queries, ensuring a smooth, hassle-free setup that prioritizes your convenience and satisfaction.
What's In The Box?
FAQ
Yes, EcoFlow DELTA Pro 3 can be connected to EcoFlow Smart Home Panel 2 through the power input/output port.
Yes, EcoFlow DELTA Pro 3 can be connected to the EcoFlow 50 Amp Hub dedicated for EcoFlow DELTA Pro Ultra via the AC Power IN/OUT port, supporting the parallel connection of up to 2 sets of EcoFlow DELTA Pro 3.
EcoFlow DELTA Pro 3 has two PV input ports, which are for high-voltage PV port and low-voltage PV, respectively.High-voltage PV: 30-150V, 15A Max, 1600W Max. Low-voltage PV: 11-60V, 20A Max, 1000W Max.
When the device is powered off, press and hold the power button for more than 5 seconds. The device's LCD screen will light up, and then the screen will blink once (it must blink once), indicating that the Bluetooth connection has been successfully reset.
Yes, it supports Level 1/2 EV chargers. You will need to purchase a dedicated EcoFlow adapter, the EV X-Stream Adapter (DELTA Pro Ultra). Typyically, the grid charging port on the US model only supports AC 120V 2000W charging (Level 1). However, by using the AC POWER IN/OUT port along with the EV X-Stream Adapter (DELTA Pro Ultra), you can connect a 240V EV charger, increasing the charging rate to 4000W (Level 2).
No, but it can perform split-phase output as a standalone unit.There are two buttons for AC output: 120V AC ON/OFF and 240V AC ON/OFF.1. When the 120V AC button is pressed, four 120V 20A outlets and one 30A RV outlet will supply power, and the 240V outlet will be turned off.2. When the 240V AC button is pressed, one L14-30 split-phase outlet and one 6-20R 240V outlet output power, and the 120V outlet will be turned off.
Yes, it will.However, there are specific requirements for the light conditions. In weak lighting environments, it might not trigger the device to power on.
- EcoFlow 800W Alternator Charger
- EcoFlow Smart Home Panel 2
- EcoFlow Smart Generator (Dual Fuel)
- EcoFlow DELTA Pro to Smart Generator Adapter
- EcoFlow PowerInsight Home Energy Manager
- EcoFlow WAVE 2
- EcoFlow Smart Generator 4000 (Dual Fuel)
Please note that all devices need to be upgraded to the latest firmware version to ensure compatibility.
- EcoFlow DELTA Pro Smart Extra Battery
- EcoFlow 50 Amp Hub (DELTA Pro Ultra)
- EcoFlow EV X-Stream Adapter (DELTA Pro Ultra)
- EcoFlow DELTA Pro Remote Control
Please note that all devices need to be upgraded to the latest firmware version to ensure compatibility.
4000 cycles.After undergoing 4000 cycles at a rate of 0.5C/0.5C at 25°C (77°F), the battery maintains over 80% of its state of health (SoH).
Optimal operating temperature: 20°C-30°CCharging temperature range: 0℃-45℃Discharge temperature range: –10℃-45℃Recommended long-term storage temperature: 20℃-30℃
As the core component of the device, the safety and protection level of the battery pack is crucial. To better protect the battery pack and reduce the risk of short circuits and fires caused by water ingress, the EcoFlow DELTA Pro 3 battery pack is sealed. It has reached an IP65 waterproof and dustproof rating, effectively preventing dust from entering and resisting water spray.However, the EcoFlow DELTA Pro 3 main unit does not have a waterproof and dustproof rating (IP20). The device is suitable for use in well-ventilated indoor environments or sheltered outdoor environments to avoid the impact of rain and dust on the device. Please ensure that the surrounding environment is dry and clean during installation and use to ensure the device's normal operation and longevity.
EcoFlow DELTA Pro 3 is equipped with an internal GFCI ground circuit. Users can connect an external GFCI protector according to their needs. When an external GFCI protector is connected to EcoFlow DELTA Pro 3, the GFCI support switch must be turned on in the app for the external GFCI protector to function properly.
Yes, supported. Please note that all devices need to be upgraded to the latest firmware version to ensure compatibility.
No, not supported.
Supported. However, due to the different capacities of the EcoFlow DELTA Pro Extra Battery and the EcoFlow DELTA Pro 3 Extra Battery, there will be some SOC imbalance.
No, not supported.
Specs
Capacity
4096Wh
4000W,6000W(X-Boost)
Supports up to two DELTA Pro 3 Smart Extra Batteries / DELTA Pro Smart Extra Batteries
AC Output
7 outlets, 4000W Max. (Surge 8000W)
Max Device(s) Power Supported by X-Boost
6000W
USB-A Fast Charge
USB-A*2, 5V 2.4A 9V 2A 12V 1.5A 18W Max
USB-C Output
USB-C*2, 5/9/12/15/20V 5A 100W Max.
12V DC Output
12.6V/30A 378W Total
DC5521 * 1, 5A Max.
Anderson Port * 1, 30A Max.
AC Charging Input
100-240V~15A,50/60HZ
120V 1800W Max.
240V 3600W Max.
Solar Charging Input
2600W, 2 ports:
HPV:30-150V/15A, 1600W Max.
LPV:11-60V/20A, 1000W Max.
Car Charging Input
12V 8A Max.
48V 20A Max.
Battery Chemistry
LFP
Cycle Life
4000 cycles to 80% capacity
Connection
WiFi 2.4GHz/Bluetooth/CAN
Net Weight
51.5kg (113.54 lb)
Dimension
693mm*341mm*410mm
EcoFlow DELTA Pro 3 Compatiblity*
*Please note that EcoFlow DELTA Pro 3 is not compatible with EcoFlow DELTA Pro/EcoFlow DELTA Pro Ultra.
EcoFlow Smart Home Panel 2 (or Smart Home Panel 2 bundle) + Installation fee Installation Terms & Conditions
Installation Conditions
1. Home circuits that have been modified by customer without permission from the government will not meet the installation conditions.
2. If customer's home is such that the required wiring length may cause voltage drop and not satisfy NEC requirements, the installation may not be possible.
3. In the event of unforeseen circumstances that may prevent inistallation, EcoFlow reserves the right to determine the final feasibility of installation.
Description of the Installation Service Package
1.To support sales of Smart Home Panel 2 or Smart Home Panel 2 bundle in North America through the EcoFlow US official website, EcoFlow offers an installation service package, which includes the basic installation cost for Smart Home Panel 2.
2.Customers who purchase EcoFlow Smart Home Panel 2 or EcoFlovw Smart Home Panel 2 bundle through Shopify may opt to purchase the "Installation service Package". EcoFlow customer service is responsible for matching the customers with electricians who can take the orderand for following up on the progress of the installation.
3.Installation Service Package includes wiring the EcoFlow Smart Home Panel 2 to the existing load center. It does not include pulling permits from AHD (If required by customers, addiitional fees may apply), wiring the EcoFlow Smart Home Panel 2 to a generator, or wiring thee EcoFlow Power Station to solar panels or PV systems. If the customer requires the installation to include wiringthe EcoFlow Smart Home Panel 2 to generator, or wiring to solar panels or PV systems, the electrician reserves the right to refuse to take the order.
4.The installation service fee on the official website covers labor costs and the materials needed for installing Smart Home Panel 2 within 2 feet of the load center. This excludes:
a.Additional material and labor costs due to excessive distance or incompatibility between the existing circuit breaker and Smart Home Panel 2.
b. Permit application fees incurred under applicable laws and regulations in certain areas.
c. The electrician's on-site assessment fee, which can be waivedif the circumstance has been assessed by the electrician to be suitable for installation and the customer does not request for refund of the installation service fee.
The above extra costs and fees shall be subject to the actual quote from the electrician. Customers are responsible for directly paying the electrician for any extra costs ircurred. EcoFlow reserves the right to final interpretation of the installation service fee.
5.By agreeing to EcoFlow's installation services, you consent to the collection and processing of personal information necessary for completing the service. This may include, but is not limited to, your name,address, contact information, and any relevant details related to the installation. We will handle your personal information in compliance with applicable data protection laws and regulations and will only use it for the purpose of fulfilling the installation service. Please refrain from directly providing your personal information to the electrician during the installation process, otherwise you will be responsible for any loss or damage caused by the disclosure of such information.
Risk Statement of the Installation Service Package
1. The option for the installation service package is based on purchase of Smart Home Panel 2.
2. If, after purchasing Smart Home Panel 2, it is concluded through the electrician's assessment that the customer's home situation does not allow for installation of Smart Home Panel 2 and a return of Smart Home Panel 2 is necessary, the cost incurred for the electrician's on-site assessment will be borne by the customer.
3. Should a customer opt for our installation service and then decide to return the Smart Home Panel 2 due to dissatisfaction after installation, the paid installation fee cannot be funded. Additionally, the customer will be responsible for any costs associated with the removal of Smart Home Panel 2.
4. The installation service does not include any cleaning or removalof debris generated during the installation process. Residents are responsible for managing and disposing of all trash and debris resulting from the installation.
5. Any holes or modifications made to the premises during theinstallation are considered normal and necessary for the proper completion of the service. The installer shall nnot be held liable for any unavoidable damages or alterations made to the premises during the installation process.
6. Any additional costs arising from the need for extra materials or labor due to a complex installation environment shall be the responsibility of the resident. These costs must be settled by the resident when completing the installation.
7. Any product issues or defects resulting from installation by an unauthorized installer shall be the sole responsibility of the resident. The resident shall bear full responsibility or any after-sales service or repairs needed due to such unauthorized installations.
*Qualifying battery storage technology of 3kWh or more must be installed by a connection to a dwelling in the United States, lived in by the taxpayer. You should always consult your tax professional to determine your eligibility for the Residential Clean Energy Credit under Section 25D of the Internal Revenue Code given your individual situation. EcoFlow does not guarantee any tax credit based on our products, and any information we provide is for educational purposes only and should not be considered legal advice. It does not constitute professional tax advice or financial guidance. It should not be used as the only source of information when making purchasing decisions, investment decisions, tax decisions, or execution. Consult a tax professional to evaluate your eligibility.
Effective date: Jan 1, 2023
